Greensmaster® Flex™ 1021 (04860)
Toro’s line of flex-head walk-behind greensmowers have been engineered to bring each operator and greensmower into perfect harmony with one another. Multiple innovations – starting with an industry-first telescoping handle – come together to deliver unparalleled cut quality and consistent playability on each and every green. The modular design also makes the Greensmaster Flex Series mowers easier than ever to maintain, saving significant time and money and lowering the total cost of ownership.
Proven Flex Suspension (Patented)
Superior contour following capability utilises an integrated "Flex" linkage system to allow cutting units to pivot around the centre of the front roller to master undulations and prevent side-to-side scrubbing of the putting surface.
Proven Honda GX 120 Engine
3.5 HP (at 3600 RPM) Honda engine with ample power for cutting and accessorising.
Tool-free Cutting Unit Removal
Changing cutting units is simple with the tool-free quick-change levers. Easily swap out cutting units in seconds and minimise maintenance downtime.
EdgeSeries™ Reels
Dual Precision Adjustment (DPA) cutting units – featuring Toro’s EdgeSeries™ reels combine to deliver a consistent, high quality cut and superior after cut appearance, while reducing maintenance with improved reel edge retention. Learn More.
Telescoping Handle
Engineered to accommodate operators of different heights, for mowing in a natural upright position. Leads to less fatigue and a superior cut. Adjustable to five distinct handle positions.
Handle Isolation Mounts
Two rubber grommets eliminate minor oscillations in Height-of-Cut caused by walking strides. Delivers a consistent cutting height on each and every green for optimal playability.
Dual Function Bail
A single bail combines safety and ease-of-operation. Convenient operation allows the mower to slow down or come to a full stop during turn-arounds without disengaging traction to line up for next mowing pass. Also ideal when using turn-around mats to preserve collar health.
Reel Engagement Lever
Convenient, easy to reach location to engage reel from the operator position.
Easy-Reach Adjustable Throttle
All operator controls are within easy reach to perfect the mowing process, improve cut consistency, and enhance control – in normal and tight turn-around situations.
Hi-Lo Clip Rate Knob
Clip frequency can easily be changed in the field to mow the perimeter, collars etc. The quick-change feature also can be locked out for added control.
Durable Gear Drive Transmission
Provides long life and best-in-class transmission durability. Lubricated for life, no grease points.
Modular Sub-Assembly Design
Make repairs simple and quick. The engine , transmission, drum or cutting unit sub-assemblies can be easily removed for timely and cost effective replacement or repair.
Traction Release Lever
Disengage the traction with a simple lever twist. Getting around the shop has never been easier!
Greensmaster® Flex™ 1021
Greensmaster® Flex™ 1021
Greensmaster® Flex™ 1021
Greensmaster® Flex™ 1021
| Blade | EdgeSeries™ DPA radial reels |
| Clip Frequency/Backlapping | Quick-change dual-speed gear drive, combined with positive drive belt - four possible reel speed/clip settings |
| Clutch | Externally-mounted two sided dry disc clutch actuated by dual motion bail |
| Controls | Engine mounted: recoil starter, choke, fuel shutoff. Handle mounted: on/off switch, throttle lever, dual motion traction / safety bail, reel engage lever, service/park brake lever, hour meter, light switch (optional) |
| Cutting Unit Accessories | 11, 14-Blade Flex ES Cutting Unit, Front and Rear Roller Options, Bedknife Options, Groomer Options, Scraper Options, Tools and Maintenance Options |
| Cutting Unit Suspension | Flex |
| Cutting Unit Type/Configuration | Tool-free cutting unit removal for service/maintenance or cutting unit exchange for different uses |
| Drivetrain | Petrol |
| Engine Cooling | Air Cooled |
| Fuel / Power Source | Petrol |
| Fuel Capacity | 2 L |
| Ground Speed - Forward | 0 - 8.5 km/h |
| Handle | Loop handle with telescoping adjustment of 5" (12.7 cm) total travel, rubber isolated to minimize operator influence during mowing |
| Height of Cut Range | For Greens: (Spacer Position One) 1.5 mm - 6 mm For Tees: (Spacer Position Two) 3 mm - 9 mm High Height of Cut Kit: 9 mm - 25 mm |
| Kickstand | Standard |
| Main Frame/Chassis | Fully modular design allows quick disassembly for service / maintenance of all major components |
| Mowing Speed | 3.2 - 5.6 km/h |
| Number of Blades | 11, 14 |
| Optional Accessories | LED Light Kit, Cutting Unit Light Kit Mount, Push Broom Kit, Wheel Kit, Backlap Access Kit, High Height of Cut Kit, Wireless Hour Meter |
| Parking/Service Brakes | Service/parking – band type |
| Power Train (Engine Description) | Honda® GX120 - 3.5 hp (2.6 kW) @3600 rpm, gasoline with integral lighting coil |
| Reel Diameter | 12.7cm |
| Reel/Cylinder Drive | Mechanical/Belt |
| Starting | Recoil |
| Tyres - Rear | Optional - Two quick-detachable pneumatic tyres 7.62 cm x 8.255 cm - 15.24 cm |
| Traction Drive | Gear |
| Traction Drive (System) | Full gear drive transmission with integral traction differential and traction drive disconnect to ease movement during service/maintenance operations. Interchangeable drum drive gear cases |
| Traction Drum | Tapered traction drum for improved after cut appearance |
| Weight | 130 kg with 11-blade cutting unit, aluminum Wiehle roller |
| Width of Cut | 53.3 cm |
| Download | Type | Information |
|---|---|---|
| Greensmaster® Flex™ 1021 | Sell Sheet |
